600 L

800 L

1250 L

1500 L

2000 L

DN32

DN40

DN40s

DN50

DN50s

Kvs = 7,2

V'max[100mbar] = 2,3m³/h

Q'max = 53kW [20K] = 22l/min [10/45°C]

Kvs = 8,5

V'max[100mbar] = 2,7m³/h

Q'max = 63kW [20K] = 26l/min [10/45°C]

Kvs = 12,5

V'max[100mbar] = 4,0m³/h

Q'max = 92kW [20K] = 38l/min [10/45°C]

Kvs = 10

V'max[100mbar] = 3,2m³/h

Q'max = 74kW [20K] = 30l/min [10/45°C]

Kvs = 16

V'max[100mbar] = 5,1m³/h

Q'max = 120kW [20K] = 48l/min [10/45°C]

DN25s

DN32

Erzeugerkreis (HT-RLA):

Kvs = 12,9 • V'max[250mbar] = 6,5m³/h

Q'max[20K] = 151kW • Q'max[10K] = 76kW

Erzeugerkreis (HT-RLA):

Kvs = 18,9 • V'max[250mbar] = 9,5m³/h

Q'max[20K] = 221kW • Q'max[10K] = 110kW

am Mischkreisvorlauf (5)

Fließrichtung Erzeuger rechts

Fließrichtung Verbraucher rechts

DN20

DN32

DN40

DN40s

DN50

DN50s

Kvs = 3,5

V'max[100mbar] = 1,1m³/h

Q'max = 26kW [20K] = 11l/min [10/45°C]

Kvs = 6,4

V'max[100mbar] = 2,0m³/h

Q'max = 47kW [20K] = 19l/min [10/45°C]

Kvs = 8,5

V'max[100mbar] = 2,7m³/h

Q'max = 63kW [20K] = 26l/min [10/45°C]

Kvs = 12,5

V'max[100mbar] = 4,0m³/h

Q'max = 92kW [20K] = 38l/min [10/45°C]

Kvs = 10

V'max[100mbar] = 3,2m³/h

Q'max = 74kW [20K] = 30l/min [10/45°C]

Kvs = 16

V'max[100mbar] = 5,1m³/h

Q'max = 120kW [20K] = 48l/min [10/45°C]

DN25s

1. Mischkreis (HT):

Kvs = 13,3 • V'max[100mbar] = 4,2m³/h

Q'max[20K] = 98kW

2. Mischkreis (NT) mit ST DN25s:

Kvs = 7,2 • V'max[100mbar] = 2,3m³/h

Q'max[10K] = 27kW

ohne (0)

Fließrichtung Erzeuger links

DN25s

Kvs = 9,1

V'max[100mbar] = 2,9m³/h

Q'max = 33kW [10K] = 67kW[20K]

ohne (0)

Fließrichtung Erzeuger rechts

RTB DN15 (Fbh)

DN15

DN20

DN25

DN32

Kvs = 1,8

V'max[100mbar] = 0,57m³/h

Q'max = 9,3kW [20K] • Q'max[10K] = 6,6kW

Kvs = 1,8

V'max[100mbar] = 0,57m³/h

Q'max = 9,3kW [20K] • Q'max[10K] = 6,6kW

Kvs = 2,5

V'max[100mbar] = 0,79m³/h

Q'max = 18kW [20K] = 7,5l/min [10/45°C]

Kvs = 5,7

V'max[100mbar] = 1,8m³/h

Q'max = 42kW [20K] = 17l/min [10/45°C]

Kvs = 6,7

V'max[100mbar] = 2,1m³/h

Q'max = 49kW [20K] = 20l/min [10/45°C]

RTB DN15 (Rad)

DN15

DN20

DN25

DN32

Kvs = 1,8

V'max[100mbar] = 0,57m³/h

Q'max = 9,3kW [20K] • Q'max[10K] = 6,6kW

Kvs = 1,8

V'max[100mbar] = 0,57m³/h

Q'max = 9,3kW [20K] • Q'max[10K] = 6,6kW

Kvs = 2,5

V'max[100mbar] = 0,79m³/h

Q'max = 18kW [20K] = 7,5l/min [10/45°C]

Kvs = 5,7

V'max[100mbar] = 1,8m³/h

Q'max = 42kW [20K] = 17l/min [10/45°C]

Kvs = 6,7

V'max[100mbar] = 2,1m³/h

Q'max = 49kW [20K] = 20l/min [10/45°C]
