300 L

400 L

DN25

DN32

DN25s

Charging circuit (HT):

Kvs = 13.3 • V'max[100mbar] = 4.2m³/h

Q'max[20K] = 98kW

Mixing circuit (NT):

Kvs = 12.9 • V'max[100mbar] = 4.1m³/h

Q'max[10K] = 48kW

without (0)

on the heat generator flow (1) and mixing circuit flow (5)

Flow direction Producer left

DN25s

Downstream assembly (HT):

Kvs = 13.9 • V'max[100mbar] = 4.4m³/h

Q'max[20K] = 102kW

Additional mixing circuit (NT) with ST DN25s:

Kvs = 7.2 • V'max[100mbar] = 2.3m³/h

Q'max[10K] = 27kW

without (0)

on the mixing circuit flow (5)

with in. Mixing circuit pump (a)

on the heat generator flow (1) and in. Mixing circuit pump (a)

Flow direction Producer left

DN25s

Kvs = 9.1

V'max[100mbar] = 2.9m³/h

Q'max = 33kW [10K] = 67kW[20K]

without (0)

Flow direction Producer right

RTB DN15 (wheel)

DN15

DN20

DN25

DN32

Kvs = 1.8

V'max[100mbar] = 0.57m³/h

Q'max = 9.3kW [20K] • Q'max[10K] = 6.6kW

Kvs = 1.8

V'max[100mbar] = 0.57m³/h

Q'max = 9.3kW [20K] • Q'max[10K] = 6.6kW

Kvs = 2.5

V'max[100mbar] = 0.79m³/h

Q'max = 18kW [20K] = 7.5l/min [10/45°C]

Kvs = 5.7

V'max[100mbar] = 1.8m³/h

Q'max = 42kW [20K] = 17l/min [10/45°C]

Kvs = 6.7

V'max[100mbar] = 2.1m³/h

Q'max = 49kW [20K] = 20l/min [10/45°C]
